Pollo-PLC-HS303-Advanced Security Products

11,500.00

PLC-HS303-T

Guardian Apex 360°

  • 3MP Smart 360 Degree PTZ Wi-Fi Camera
  • 10m Color Night Vision
  • Built-In Two Way Audio
  • Built-In Micro-SD Card Slot Upto 128GB
  • Support Continuous Recording
  • Sound & Light Alarm & Human Tracking
  • Support Cloud Storage
  • Support ONVIF & IP66




Product modelPLC-HS303-T
Form FactorPT Dome Camera
Product ColourWhite
Antennaexternal antenna
MaterialsABS + PC + Anti - UV
Surface FinishingDumb face or grain
waterproof levelIP66
Dimension(L*W*H)(mm)119*89*86mm
Flash8MB
optics4.0mm,F2.6 aperture, waterproof
Viewing angleD*H*V 101°*85°*45°
Image circleØ7
DimensionM12*22.9mm;
Sensor TypeMIS2008
Resolution2304*1296 Pixel
Night Vision10M distance
IR-LED3pcs IR(IR+White)led*0.5W
WHITE-LED10m (850nm), White light colour temperature:4000K(pure white)
IR-CUTNormal
photosensitiveColour cut black ≤0.5Lux; Cut the black colour≥ 8.5Lux
Working Indicatorred green light*1
StandardRTL8188FTV
MicFull duplex, sensitivity: ≥-32±3dBm, IP66 waterproof
SpeakerBuilt-in 8 ω /2W, IP66 waterproof
TF CardMax support 128G
Button SwitchReset *1
EthernetAside: JL1101
Antenna3DBi * 1
Horizontal angle336°
Vertical angle108°
Wifi Maximum rate54 Mbps
Wifi distanceopen≥120m
Wifi standardIEEE 802.11 b/g/n, single frequency 2.4G
Power SupplyUSB Port 5V
Operational power consumptionMax 4.5W
I/O Input portTF Card*1, Mic*1
I/O Power portUSB2.0,2P/1.5mm, 3M long
I/O Ethernet portReserved: 6P/1.25 (4P network +2P power supply) No network indicator/power indicator;
I/O Output portSpeaker*1
I/O key typeReset*1;
I/O Indicator lightRed and green two-colour indicator light*1;
Echo cancellationSupport
Two-Way TalkSupport
Start-up the bellSupport
Rest the bellSupport
Compression methodG.711A
Video FormatH.264
Video frame rateDay:20fps; Night:15fps
Resolution & frame rate2304*1296 Pixel, Multi-bit stream, adaptive;
IR turned ONEnable night vision view, IR, ICR auto detection
IR turned OFFDisable night view, turn off infrared, ICR stays in day view mode;
AndoridAndroid 4.3+
IOSIOS 9.X-10.X more
Mobile APPCloud Edge
Cloud platformAmazon
LanguageChinese, English, French, German, Italian, Spanish, Japanese
Basic functionSupport configuration/real-time preview/screenshot/playback/intercom/video adjustment /recording/PTZ/cloud storage
Cloud recording storageSupport
Online visitorMax 5 user
Type of AlarmSupport push message, sound and light alarm
Human tackingSupport
Detection Sensitivitylow/medium/high, default medium
Audible alarm3 options (default white light is always on)
Remote control and monitoringSupport
Power failure memorySupport
OnvifOptional
PairingQR code add, AP hotspot
OTA upgradeSupport
Green Light slow flashpreview image
Green Light Always brightUnreviewed image
Green Light Always brightonline
Green Light slow flashrunning normally
Red Light slow flashThe device enters this state when it is powered on and no network is configured
Red Light Quick flashDuration: Until the network is configured successfully
Red Light Quick flashUntil the upgrade succeeds or fails - (the green light is always on when the upgrade is successful)
Red Light Red light quick flashThe network status is the same as device
Reset the deviceNormal connection indicator status: red light flashes slowly -> red light flashes quickly -> green light is always on; The red-light flashes slowly when the network is not configured. When the user connects to the 2.4G network and scans the code for the device, the red-light flashes quickly; The red-light flashes quickly to indicate that the server is being connected; the indicator is steady green, the network is online successfully;
Restart the deviceRed light flashes slowly > red light flashes quickly -> green light is always on
Broken networkRed light flashes quickly
PackagePearl cotton, giftbox, 3m USB cable, positioning sticker
Temperature settingworking: -20 ~ 60 ℃, Humidity <95% Storage:-25 ~ 65 ℃, Humidity <95%
