Pollo 8-Port POE Switch PLN-1108MGB

Original price was: ₨16,500.00.Current price is: ₨15,800.00.


8-Port AI PoE Switch With 2GB Uplink

• 08 Ports PoE
• 2 Gigabit Uplinks
• Long Distance: 100m
• IEEE 802.3 af/at
• Lightning Protection: 4KV
• Power Capacity: 120W
• Support DIP Switch for 250m Distance

Product NamePLN-1108MGB
Fixed Port8*10/100Base-TX PoE ports (Data/Power) 2*10/100/1000Base-T uplink RJ45 ports (Data)
Ethernet PortPort 1-8 can support 10/100Base-T X auto detect, port 9-10 can support 10/100/1000Base-T auto detect, full / half duplex MDI / MDI-X adaptive
Functional Switch1*(Extender) Note: when the switch state changes, it must be restarted before the PoE switch function can take effect
Twisted Pair Transmission10BASE-T: Cat3,4,5 UTP (≤250 meter) 100BASE-TX: Cat5 or later UTP (≤100 meter) 1000BASE-T: Cat5e or later UTP (≤100 meter)
Network ProtocolIEEE802.3 10BASE-T, IEEE802.3i 10Base-T IEEE802.3u 100Base-TX, IEEE802.3x
Forwarding ModeStore and Forward (Full Wire Speed)
Switching Capacity11.8Gbps (non-blocking)
Forwarding Rate@64byte4.17Mpps
Buffer Memory2M
LED IndicatorPower: PWR (green), network: Link (yellow), PoE: PoE (green) Functional switch: EXTEND (green)
PoE PortPort 1 to 8 IEEE802.3af/at @POE
Power Supply PinDefault 1/2(+), 3/6(-), optional 4/5(+), 7/8(-) 2-pairs power supply
Max Power Per Port30W, IEEE802.3af/at
Total PWR / Input Voltage120W/ (AC100-240V)
Power ConsumptionStandby <5W, Full load <120W
Power SupplyBuilt-in power supply, AC100~240V 50-60Hz 2.2A
Operation TEMP / Humidity-20~+55°C;5%~90% RH Non condensing
Storage TEMP / Humidity-40~+75°C;5%~95% RH Non condensing
Dimension (L*W*H)195*130*40mm
Net /Gross Weight<0.8kg / <1.2kg
InstallationDesktop, wall mounted
Lightning protection / protection levelLightning protection: 4KV 8/20us; Protection level: IP30
CertificationCCC, CE mark, commercial, CE/LVD EN60950 FCC Part 15 Class B, RoHS
