Description
Technical Specifications
| Output Power Capacity
| 8000 Watt / 10 kVA
|
| Maximum Configurable Power
| 8000 Watt / 10 kVA
|
| Nominal Output Voltage
| 230V
|
| Output Voltage Note
| 220: configurable for 230 or 240 nominal output voltage
|
| Output Voltage Distortion
| Less than 3%
|
| Output Frequency (from the sync to the main input)
| 50 / 60Hz +/- 3 Hz
|
| Crest Factor
| 3: 1
|
| Topology
| Double Conversion On-Line
|
| Waveform Type
| Sine wave
|
| Output Connection
| (1) Hard Wire 3-wire (HN + G)
|
| Bypass
| Built-in Bypass (Automatic and Manual)
|
Login
| |
| Nominal Input Voltage
| 230V
|
| Input frequency
| 47 – 63 Hz
|
| Input Connection Type
| Hard Wire 3 wire (1PH + N + G)
|
| Input Voltage scale for main operations
| 160 – 280V
|
| Input Voltage can be set for main operations
| 100 – 280V
|
| Other Input Voltage
| 220, 240
|
| Maximum Input Current
| 60A
|
| Input Circuit Breaker Capacity
| 63A
|
| Input Total Harmonic Distortion
| Less than 8% for full load
|
Ak?ler & Runtime
| |
| Battery type
| VRLA
|
| Typical recharge time
| 8 hours (s)
|
| Extended working option for
| APC Smart-UPS RC 10000VA 230V
|
Communication & Management
| |
| Interface port
| DB-25 RS-232, Smart-Socket
|
| Control Board
| LED status indicator with load and power supply bar graph and On Line: At Power Supply: Change Power Supply: Overload and Bypass Indicators
|
| Audible alarm
| Battery-operated alarm: special low battery alarm: continuous tone overload alarm
|
| Emergency Power Cutting (EPO)
| Optional
|
Surge Protection and Filtering
| |
| Surge energy rating
| 420 Jul
|
| Filtering
| Full-time multi-pole audio filtering 0.3% IEEE mishap: UL 1449’s fast response response time:
|
Physical
| |
| Maximum height x width x depth dimensions
| 440.00 mm x 262.00 mm x 628.00 mm
|
| Cab Elevation
| 6U
|
| Net weight
| 86.50 KG
|
| Shipping Weight
| 106.50 KG
|
| Shipping Height x Width x Depth
| 600.00 mm x 526.00 mm x 750.00 mm
|
| Color
| Black
|
About the medium
| |
| Operating Environment
| 0 – 40 ? C
|
| Operating Relative Nemi
| 0 – 95% no%
|
| Operating Elevation
| 0-600 meters
|
| Storage Temperature
| -20 to 50 ? C
|
| Storage Relative Humidity
| 0 – 95%
|
| Storage Height
| 0-3000 meters
|
| Audible noise at 1 meter from the surface of the unit
| 60.00 dBA
|
| Online thermal distribution
| 652.00 BTU / s
|
Compatibility
| |
| Approvals
| CE, CE Mark, EN / IEC 62040-2, IEC 62040-2
|
| Standard warranty
| 2 years, repair or replacement
|
Sustainable Offer Status
| |
| RoHS
| Compatible
|
| REACH
| REACH: SVHC does not contain |
