Pollo 4 Channel DVR PLC-1504 H1 PM

Pollo 4 Channel DVR PLC-1504 H1 PM

Original price was: ₨16,500.00.Current price is: ₨15,800.00.

• 04 Channel Input
• 5 MP Resolution
• AHD/TVI/CVI/IP
• H.265+/H.265
• Output: HDMI, VGA & CVBS
• 1 SATA upto 8TB

SKU: Pollo/15
Categories: ,

Description

MODEL NAMEPLC-1504H1 Pm
MAIN PROCESSORHI3520DV400
OPERATING SYSTEMEmbedded Linux
INPUTNormal Mode: Analog: 4*(TVI/AHD: 5M@12fps; AHD/TVI/CVI: 4M@15fps; AHD/TVI: 3M; AHD /TVI/CVI: 1080P/720P; Analog: 960H) Analog + Network: 2*Analog(5MP)+4*network(MAX 5MP), Network: 9*5MP/4MP/3MP/1080P/960P/720P(Total incoming bandwidth ≤48M)
INPUT4CH BNC
SIGNAL TYPEAnalog/AHD/CVI/TVI 2.0/TVI 3.0/Network
OUTPUT1HDMI,1 VGA
AUDIO INPUT1 Channel, RCA
TWO-WAY AUDIONO
AUDIO OUTPUT1 Channel, RCA
SENSOR INPUT / OUTPUTNo
MOTION DETECTION4 Channel (max 9 Channel in pure network mode)
TRIGGER EVENTSRecording, Email, Screen tips, Buzzer, Push notifications (motion detection)
EMAIL ALARMSend Image to The Designated E-mail
FACE COMPARISON1 channel video stream face Comparison (1 face databases with 10 face images)
INTERFACERS485
PROTOCOLPelco-D, Pelco-P
BAUD RATE110~921600
ADDRESS0~255
VGAResolution: 1920 × 1080P/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,1024 × 768/60Hz
HDMI OUTPUTResolution:1920 × 1080P/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz,1024 × 768/60Hz
DISPLAY SPLIT9 Channel/4 Channel / 1Channel
PRIVACY MASKING3 Rectangular Zones (Each camera)
OSDCamera title, Time, Video loss, Alarm, Motion detection, Recording
VIDEO COMPRESSIONH.265/H.264
AUDIO COMPRESSIONG.711u/G.711a
RESOLUTION5MP_Lite(1296×1944),4MP_Lite(1280×1440),3MP_Lite(1024×1536),1080N(960×1080),720P(12 80×720),960H(P:960×576/N:960×480)
VIDEO QUALITYWorst/Worse/Ordinary/Well/Best
RECORD RATEAnalog: PAL:5MP_Lite(1296×1944 4*8fps),4MP_Lite(1280×1440 4*15fps),3MP_Lite(1024×153 6 4*18fps),1080N(960×1080 4*18fps),720P(1280×720 4*20fps), 960H(960×480 4*25fps), NTSC: 5MP_Lite(1296×1944 4*8fps),4MP_Lite(1280×1440 4*15fps),3MP_Lite(1024×1536 4*18f ps),1080N(960×1080 4*18fps),720P(1280×720 4*20fps), 960H(960×480 4*25fps), Pure IP(H.265):, PAL: 5MP@8×25fps,4MP@9x25fps,3MP@9×25fps,1080P@9×25fps,960P@9×25fps,720P@9×2 5fps,D1@9×25fps, NTSC: 5MP@8×30fps,4MP@9×30fps,3MP@9×30fps,1080P@9×30fps, 960P@9×30fps, 720P@9 ×30fps, D1@9×30fps
RECORD MODEManualTimerMotion DetectionAI Alarm
DECODE CAPABILITY2CH 1080P@30fps
SYNC PLAYBACKPure Analog: 4CH 960H@25fps, 2CH 720P@20fps, 1CH 1080N@18fps, 1CH 5M_LITE@8fps, 1CH 4M_LITE@15fps, 1CH 3M_LITE@18fps, Mixture mode: 4CH D1@25fps, 2CH 1080P@25fps, 1CH 5MP@25fps, Pure Network: 4CH D1@25fps, 2CH 1080P@25fps, 1CH 5MP@25fps
REMOTE PLAYBACK1 Channel
SEARCH MODEALL, Channel, Manual, Time, Date, Motion Detection
PLAYBACK FUNCTIONSPlay, Pause, Stop, Fast play, Slow play, Rewind, Single frame forward/back, Digital Zoom, Full sc reen
SMART PHONE PLAYBACK4 Channel
BACKUP MODEUSB Device (with format FAT 32 )/Network/FTP
INTERFACE1 RJ45 10M/100M Adaptive Ethernet Interface
NETWORK FUNCTIONSTCP/IP, HTTP, UPnP, DNS, NTP, SMTP, PPPoE, DHCP, FTP, DDNS, RTP, RTSP, RTCP
DDNSDyndns, changeip, no-ip, Oray, A-PRESS, MYQSEE, SKDDNS, SMART-EYES, ZEBEYE
WEB BROWSERIE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53)
CMS SOFTWARESupport Windows 7/ Windows 8/Windows 10
EXTRA STREAMCIF/D1(1~25fps)
SMART PHONEiPhone, iPad, Android, Android pad
INTERFACE TYPE1 SATA Interface
CAPACITY1 SATA Hard Disk (2.5″/3.5″ SATA, Up to 8TB)
LANGUAGESimplified Chinese,Traditional Chinese, English, Polish, Czech, Russian, Thai, Hebrew, Arabic, Bul garian, German, French, Portuguese, Turkic, Spanish, Italian, Hungarian, Romanian, korean, Dut ch, Greek, Vietnamese, Japanese
UTC CONTROLYES
USB INTERFACE2 USB 2.0 Interfaces
POWER CONSUMPTIONDC 12V/2A ≤4W (Without Hard Disk)
WORKING TEMPERATURE-10~55℃/10~90%
DIMENSION (W×D×H)260*215*43(mm)
WEIGHT2kg (Without HDD)
