Technical Specifications
| provided equipment |
CD with software
Documentation CD Removable support feet Smart UPS signalling RS-232 cable User manual Warranty card |
|---|
| number of rack unit |
4U
|
|
|---|---|---|
| colour |
Black
|
|
| depth |
67.1?cm
|
|
| height |
44?cm
|
|
| net weight |
55.5?kg
|
|
| width |
17.7?cm
|
| network frequency |
40…70 Hz auto-sensing
|
|
|---|---|---|
| number of input connectors |
1 hard wire 3-wire (1P + N + E)
|
|
| input voltage limits |
100…280 V adjustable
180…280 V |
|
| inputvolt_other |
220 V
240 V |
|
| maximum input current |
26?A
|
|
| switching current capacity |
40?A
|
|
| input harmonic distortion |
Less than 8 % for full load
|
|
| input voltage |
230 V
|
| rated power in W |
3500?W
|
|
|---|---|---|
| Maximum configurable power in W |
3500?W
|
|
| harmonic distortion |
Less than 3 %
|
|
| output frequency |
50/60 Hz +/- 3 Hz sync to mains
|
|
| outputvolt_other |
220 V
240 V |
|
| crest factor |
3 : 1
|
|
| UPS type |
Double conversion online
|
|
| Wave type |
Sine wave
|
|
| output connector type |
Hard wire 3-wire (H N + E) 1
|
|
| bypass type |
Internal bypass (automatic and manual)
|
|
| output voltage |
230 V
|
| product certifications |
CE
|
|
|---|---|---|
| standards |
EN 60950
EN/IEC 62040-2 |
|
| marking |
CE Mark
|
| ambient air temperature for operation |
0?40??C
|
|
|---|---|---|
| relative humidity |
0?95?% non-condensing
|
|
| operating altitude |
0…2000 ft
|
|
| ambient air temperature for storage |
-20?50??C
|
|
| storage altitude |
0.00?3048.00?m
|
|
| acoustic level |
60 dBA
|
|
| heat dissipation |
652?Btu/h
|
| battery type |
VRLA
|
|
|---|---|---|
| number of battery filled slots |
0
|
|
| number of battery free slots |
0
|
|
| Battery recharge time |
8?h
|
|
| additional information |
Configurable for 220 : 230 or 240 nominal output voltage
|
|
| liquid value |
0
|
| control panel |
LED status display with load and battery bar-graphs and on line : on battery : replace battery : overload and bypass indicators
|
|
|---|---|---|
| alarm |
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
|
|
| Emergency power off |
Optional
|
| Surge energy rate |
420?J
|
|
|---|---|---|
| noise suppression |
Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
|
| Package 1 Weight |
72.5?kg
|
|
|---|---|---|
| Package 1 Height |
60?cm
|
|
| Package 1 width |
45.6?cm
|
|
| Package 1 Length |
80.1?cm
|
| EU RoHS Directive |
Compliant
EU RoHS Declaration |
|
|---|---|---|
| WEEE |
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
|
| Warranty |
2 years repair or replace
|
|---|
